GOLDMUND TELOS 300 STEREO AMPLIFIER RELEASED

The Goldmund Telos 300 is a class AB power amplifier from the high-end Swiss brand, that integrates the latest evolutions of Goldmund proprietary Telos amplification technology.

GOLDMUND TELOS 300 STEREO AMPLIFIER

With 450 W of pure power to drive your speakers, Goldmund says their Telos 300’s improved power supply delivers more sustained low frequencies. Its design is inspired by its predecessor, the Telos 280.

Goldmund Telos 300 Stereo Amplifier

The Swiss-made Goldmund Telos 300 Stereo Amplifier

ENHANCED AMP PROTECTION

Enhanced amplifier protection includes a timer that temporarily opens its outputs when overloaded. The components used were adjusted in all the amplification stages to reduce harmonic distortions in the high frequencies and improve linearity.

Goldmund Telos 300 Stereo Amplifier

The rear panel of the Goldmund Telos 300 Stereo Amplifier

SPECIFICATIONS

OUTPUT POWER

Maximum power (IEC60065): 2 x 225 Wrms on 8 Ω / 1 % THD.

DAMPING FACTOR

173 at 1kHz / 8 Ω.

GAIN

35 dB.

DISTORTION

IMD (SMPTE), unloaded: < 0.04 %.

THD+N, unloaded: < 0.04 % from 20 Hz to 20 kHz at 20 Vrms output.

MAX POWER CONSUMPTION

IEC 60065 at 8 Ω /1 % THD: 300 W.

RATED POWER CONSUMPTION

IEC 60065, 1/8 Output Power at 8 Ω: 70 W.

INPUT

Max level before clipping, Analog input: 1 Vrms.

OUTPUT

Max level before clipping, 1 % THD, unloaded: 153 Vpp.

OUTPUT LEVEL

Maximum voltage before clipping: 153 Vpp.

REAR PANEL

2 x output binding posts (left & right).

2 x RCA Analogue Input (left & right).

2 x XLR Analogue Input (left & right).

Input Voltage selector.

OUTPUT NOISE FLOOR

Analogue input terminated with RCA Shorting Caps, unloaded: < 1.5 μV from 20 Hz to 20 kHz.

DYNAMIC RANGE

22 kHz measurement bandwidth (flat), true RMS unloaded: 118 dB.

POWER SUPPLY

Nominal line voltage: 115 V or 230 V (+/- 15 %).

Fuse: 8 A.

DIMENSIONS & WEIGHT

44 W x 40.4 D x 15.5 H (cm).

15 kg.

PRICE

£13,000
