TAGA Harmony HTA-800 Amplifier Launched
TAGA Harmony HTA-800 is a 50W / 8ohm hybrid integrated amplifier utilising two 6N3 tubes in the preamp section and four Toshiba transistors at the output. High-performance tubes and a high-power shielded toroidal 200W transformer provides stable power.
There are audiophile grade ALPS volume potentiometer, WIMA capacitors and gold-plated speaker terminals. Analog inputs with solid machined brass RCA sockets can accommodate up to 4 stereo devices including a turntable (MM cartridge). You can connect a range of digital devices via optical or coaxial inputs and there is a built-in 24bit / 192kHz DAC , it also has a headphone preamplifier. A Preamplifier output is dedicated for an optional external power amplifier or powered subwoofer and speakers.
Power Output: 2 x 60W RMS / 4ohm
2 x 55W RMS / 6ohm
2 x 50W RMS / 8ohm
Class A/B
Vacuum Tubes: 2 x 6N3
THD: 0.5%
Signal/Noise ratio: 75dB
Frequency Response: 20Hz – 20kHz
Inputs: Analog: RCA Stereo: CD, Line, AUX, Phono (MM)
Digital: Optical, Coaxial
Outputs: RCA Pre-Out
Headphones: Impedance 16Ω, Output Power 150mW
Phono input:
Input impedance 47KOhms/120pF
Gain 40dB
Input voltage 5mV @ 1kHz
THD <0.5%
SNR 72dB
Built-in DAC: 24bit / 192kHz
Cirrus Logic CS4344
Included Accessories: Aluminium Remote Controller
IEC Power cord
AC Power, Power Consumption: 220-230V 50/60Hz, 200W
Dimensions (H x W x D): 14.2 x 43 x 38 cm
Weight (net): 8.1 kg / pc.
Finishes: Black
