The Goldmund Telos 3300 Nextgen Amplifier is a 700 watt Universal Mono Power Amplifier, made by the high end Swiss Hifi brand.

The Telos 3300 Nextgen circuitry is the latest enhancement of Goldmund’s 30-year old circuit. Several R&D developers have added layers of evolution to this schematic.

The amp has the traditional Goldmund solid brass structure and metal finish applied to the aluminum external surfaces, that make the Telos 3300 Nextgen a piece of sculpture as well as an amplifier.

Technical Specifications

Power Supply

Nominal line voltage: 115 V or 230 V.

Input voltage range: +/- 15 %.

Rated Power Consumption

IEC 60065, 1/8 Output Power at 8 Ω: 500 W.

Rear Panel

Power cord: universal socket 3 lugs, 16 A.

Main fuses (see last page for more details).

AC black GND binding post (with bridge connection).

Green-yellow AC earth binding post (with bridge connection).

2 x binding post 5-way connector.

2 x Goldmund Speaker Lemo connector.

Analogue input RCA unbalanced connector.

Analogue input XLR balanced connector.

Digital input and output RCA connectors.

RS232 command connector.

Output

Max level before clipping, 1 % THD unloaded: 300 Vpp.

Output Power

Maximum power (IEC60065): 700 Wrms on 8 Ω / 1 % THD.

Distortion

IMD (SMPTE), unloaded: < 0.01 %

THD+N, unloaded: < 0.005 % from 20 Hz to 20 kHz at 30 Vrms output.

Output Noise Floor

Analogue input terminated with RCA Shorting Caps, unloaded: < 5 μV from 20 Hz to 20 kHz.

Gain

35 dB, +/- 9 dB (adjustable in steps of 3 dB for each input).

Dynamic Range

22 kHz measurement bandwidth (flat), true RMS unloaded: 116 dB.

Damping Factor

350 at 1 kHz / 8 Ω.

Size & Weight

39 W x 69 H x 48 D (cm) – 15.4 W x 27.2 H x 18.9 D (inch).

165 kg.
