The new generation of PIEGA Premium speakers boasts a fantastic quality of sound – thanks to its new LDR 3056 high-range ribbon tweeter.
The new Premium 701, 501 and 301 PIEGA speakers constitute the technical and visual continuation of one of the most successful speaker concepts produced by the Swiss manufacturer. To refine their appearance, Swiss designer Stephan Hürlemann has fitted the front covers flush into the C-shaped cabinet profile. The polished aluminium finish is also rather interesting.
While the two smaller models use the PIEGA LDR 2642 MKII tweeters, the Premium 701 flagship range is the first model equipped with the new LDR 3056 ribbon tweeters. This tweeter system benefits from all important insights gained during the development of the PIEGA Line Source Driver and the second-generation PIEGA Coax System. Its thin membrane has a newly developed suspension and is controlled by mass-free damping. The system has an extremely high degree of efficiency, greater bandwidth and linearity and an impressive resolution says the company’s recent press release.
Compared to the previous speakers, they are 30 percent more rigid. Their rounded shape prevents the occurrence of standing waves inside the cabinet. All models of the Premium series are available in three versions: silver anodised, white varnish with a silver cover, black anodised with a black cover.
Premium 701
The Premium 701 is barely larger than its smaller sister model. It also uses a 2.5-way system. Two 140 mm MDS converters cater for the bass, one of the two also handles mid-tone emission. The newly developed LDR 3056 ribbon, used here for the very first time, produces the high tones.
Premium 501
This extremely slim column loudspeaker, which is only 16 cm wide and about one metre tall. The 501 uses two long-stroke 120 mm MDS low mid-range drivers and LDR 2642 MKII ribbon.
Premium 301
The Premium 301 is a compact loudspeaker with a baffle about the size of an A4 sheet. Behind the removable fabric cover, there is a 140 mm MDS low mid-range driver and the LDR 2642 MKII ribbon tweeter.
Model | Premium 701 | Premium 501 | Premium 301 |
Construction principle | 2 1/2-way system Column loudspeaker |
2 1/2-way system Column loudspeaker |
2-way system Bookshelf loudspeaker |
Recommended amplifier power |
20 – 200 watt | 20 – 200 watt | 20 – 200 watt |
Sensitivity | 91 db/W/m | 90 dB/W/m | 89 dB/W/m |
Impedance | 4 ohms | 4 ohms | 4 ohms |
Frequency response (+/-2 dB) | 34 Hz – 50 kHz | 36 Hz – 50 kHz | 39 Hz – 50 kHz |
Low mid-range drivers | 2 x 140 mm MDS | 2 x 120 mm MDS | 1 x 140 mm MDS |
Tweeters | 1 x LDR 3056 Ribbon / NEW |
1 x LDR 2642 MKII Ribbon |
1 x LDR 2642 MKII Ribbon |
Connection | PIEGA Multi Connectors | PIEGA Multi Connectors | PIEGA Multi Connectors |
Dimensions (HxWxD) | 106 x 18 x 23 cm | 101 x 16 x 21 cm | 34 x 18 x 23 cm |
Weight | 28 kg | 21 kg | 9 kg |
Versions | Silver anodised aluminium, silver fabric cover
Black anodised aluminium, black fabric cover
White varnished aluminium, white fabric cover |
Silver anodised aluminium, silver fabric cover
Black anodised aluminium, black fabric cover
White varnished aluminium, white fabric cover |
Silver anodised aluminium, silver fabric cover
Black anodised aluminium, black fabric cover
White varnished aluminium, white fabric cover |
