TAGA Harmony, manufacturer of speakers and audio electronics, has unveiled a new high-fidelity hybrid amplifier, the HTA-1200.

TAGA Harmony HTA-1200 is a 80W/8ohm high-fidelity hybrid integrated amplifier utilising a 12AX7 tube preamp section with a cathode type amp circuit and a 12AU7 stage serving as a buffer amplifier, and four Toshiba transistors at the output.

High-performance tubes and high voltage transistor hybrid power supply provide voltage stability and very low AC ripple current. High-power toroidal 300W transformer provides constant and immediately-available energy at any volume level. The tube circuit is cross-connected with audiophile grade MKP capacitors and an audiophile grade  ALPS volume potentiometer provides minimal noise and channel crosstalk. Gold-plated speaker terminals transmit the audio signalto the speakers. Analog inputs with solid machined brass RCA sockets can accommodate up to 4 stereo devices including a turntable (both MM and MC cartridges).

You can connect a range of digital devices via optical or coaxial inputs and there is a built-in high-resolution 24bit / 192kHz DAC. The HTA-1200 is also equipped with a high-end headphone preamplifier. The preamplifier output is dedicated for an optional external power amplifier or powered subwoofer and speakers. The removable IEC power cable gives you an option to upgrade your system with a premium audiophile power cable in any time.



Power Output: 2 x 120W RMS / 4ohm

2 x 80W RMS / 8ohm

Class A/B

Vacuum Tubes: 1 x 12AX7, 2 x 12AU7
THD: Less or equal 0.1% (1kHz 1W)
 Signal/Noise ratio: 90dB
Frequency Response: 20Hz – 20kHz (+/- 0.5dB)
Inputs: Analog: RCA Stereo: CD, Line, AUX, Phono (MM/MC)

Digital: Optical, Coaxial

Outputs: RCA Pre-Out
Headphones: Impedance 32-300ohm
Output Power
350m300ohm, 1.2W(32ohm)
Phono input (MM | MC): Input impedance 47KOhms/47pF | 100ohms/47pF
Gain 60dB | 54dB

Input voltage 58mV | 6.8mV

THD <0.05%
SNR >83dB  | >70dB

Built-in DAC : 24bit / 192kHz

Texas Instruments PCM-5100

Included Accessories: Full Aluminum Remote control
Removable IEC Power cord
AC Power, Power Consumption: 220-230V 50/60Hz, 300W
Dimensions (H x W x D): 11.8 x 43 x 37.5 cm
Weight (net): 11.5 kg / pc.
Finishes: Black
